Hydraulic piston pump AVP500

Hydraulic piston pump AVP500
Product name : Hydraulic piston pump AVP500
Item : 2019511211224
Details :
Hydraulic piston pump AVP500

AVP500H pump axial variable displacement pump, the pump

With through shaft structure, compared with half shaft structure, it is smaller in volume and lighter in weight. And because we solved the column

The thrust return force is in conflict with the initial sealing pressure on the oil distribution surface, so the rotating speed is greatly increased. Adopts spherical

Oil distribution and other special structures reduce running noise, improve efficiency and prolong service life.

How to order:

Technical datasheet:



Model
Displacement(ml/r)
Pressure(mpa)
Speed(r/min)
Rated
Max
Rated
AVP500H
500
31.5
40
1500

[Next : 2019412145336]→
