Hydraulic internal gear pump NT5-G80F, high pressure type

Hydraulic internal gear pump NT5-G80F, high pressure type
Product name : Hydraulic internal gear pump NT5-G80F, high pressure type
Item :
Details :
Hydraulic internal gear pump NT5-G80F, high pressure type

How to order:



NT gear pump drawing.jpg

Drawing size:

Series NT2- NT3- NT4- NT5-
Type C D G C D G C D G C D G
A 134 172 214 266

B
metric  109 140 180 224
British  106 146 181 229
C 11 14 18 23
I 48 68 92 92
K 90 115 145 154
L 226 205 250 283 245 312 347 313 383 415 373 463
M 115 94 139 141 114 170 170 136 206 216.5 174.5 264.5

N
metric  Φ80h8 Φ100h8 Φ1250h8 Φ160h8
British  Φ82.55 0/-0.05 Φ101.6 0/-0.05 Φ127.0 0/-0.05 Φ152.4 0/-0.05
O 12 16 20 24
T 115 139 170 216
V 4 7 7 7
Z 60 75 93 118
D Φ25+0.009/-0.004 Φ32+0.011/-0.005 Φ40+0.011/-0.005 Φ50+0.011/-0.005
E 42 58 82 82
F 8  0/-0.036 10   0/-0.036 12   0/-0.043 14   0/-0.043
G 28.1 35.0 43.0 53.5
Q 36 50 70 70
S Φ30 Φ38 Φ50 Φ64
P Φ20 Φ25 Φ30 Φ38
X1 30 36 43 51
X2 22 26 30 36
Y1 59 70 78 89
Y2 48 52 59 70
4-d1 M10*25 M12*30 M12*30 M12*30
4-d2 M10*25 M10*25 M10*25 M12*30
Weight(KG) 13.1 11.7 14.2 22.9 20.5 23.3 43.0 38.3 48.4 88.0 75.0 99.0

The high pressure type models:

NT2-G10F,NT2-G12F,NT2-G16F,NT3-G20F,NT3-G25F,NT3-G32F,NT4-G40F,NT4-G50F,NT4-G63F,NT5-G80F,NT5-G100F,NT5-G125F



Strengths:Silent,long life,low pulsation,good oil inhalation,low sensitive to oil pollution and reliable working performance.
