Hydraulic internal gear pump NT2-C20F, low pressure type

Hydraulic internal gear pump NT2-C20F, low pressure type
Product name : Hydraulic internal gear pump NT2-C20F, low pressure type
Item :
Details :
Hydraulic internal gear pump NT2-C20F, low pressure type


How to order:



NT gear pump drawing.jpg

Drawing size:

Series NT2- NT3- NT4- NT5-
Type C D G C D G C D G C D G
A 134 172 214 266

B
metric  109 140 180 224
British  106 146 181 229
C 11 14 18 23
I 48 68 92 92
K 90 115 145 154
L 226 205 250 283 245 312 347 313 383 415 373 463
M 115 94 139 141 114 170 170 136 206 216.5 174.5 264.5

N
metric  Φ80h8 Φ100h8 Φ1250h8 Φ160h8
British  Φ82.55 0/-0.05 Φ101.6 0/-0.05 Φ127.0 0/-0.05 Φ152.4 0/-0.05
O 12 16 20 24
T 115 139 170 216
V 4 7 7 7
Z 60 75 93 118
D Φ25+0.009/-0.004 Φ32+0.011/-0.005 Φ40+0.011/-0.005 Φ50+0.011/-0.005
E 42 58 82 82
F 8  0/-0.036 10   0/-0.036 12   0/-0.043 14   0/-0.043
G 28.1 35.0 43.0 53.5
Q 36 50 70 70
S Φ30 Φ38 Φ50 Φ64
P Φ20 Φ25 Φ30 Φ38
X1 30 36 43 51
X2 22 26 30 36
Y1 59 70 78 89
Y2 48 52 59 70
4-d1 M10*25 M12*30 M12*30 M12*30
4-d2 M10*25 M10*25 M10*25 M12*30
Weight(KG) 13.1 11.7 14.2 22.9 20.5 23.3 43.0 38.3 48.4 88.0 75.0 99.0

The low pressure type models:

Internal gear pump NT2-C20F,NT2-C25F,NT2-C32F,NT3-C40F,NT3-C50F,NT3-C63F,NT4-C80F, NT4-C100F,NT4-C125F,NT5-C160F,NT5-C200F,NT5-C250F

How to choose suitable gear pump?


A. First of all, it depends on the layout of the equipment. There are water level conditions, operation conditions, horizontal installation or vertical installation.

B. Look at the liquid, hydraulic oil, water, or chemical required in the setting to determine the relevant gear pump.

C. Also depends on the amount of equipment needed, how much head, speed efficiency, etc., select the appropriate gear pump.

D. According to the working time and frequency of gear pump, select the appropriate pump and spare gear pump

These are some common methods, welcome to exchange.
